MediaClone SuperCopier Desktop Pro Gen 3 Drive Duplicator with 8 x SAS/SATA Ports

The SuperCopier Desktop Pro Gen 3 Drive Duplicator with 8 x SAS/SATA Ports from MediaClone is an industrial multiple-purpose standalone drive copier and drive duplication unit. It can be used to perform drive duplication, drive imaging, drive cloning, drive erase, drive diagnostics, selective capture, and drive quick format of many drives (hard drives and SSDs) quickly and efficiently. The unit performs at a very high transfer rate in a secure Linux environment, and is operated via user-friendly touchscreen application. The unit has a durable desktop-style build, with an eight-channel open tray for easy drive insertion and connection, eight SATA / SATA 3 ports, ten USB 3.1 ports (two Gen 2), and three eSATA interfaces. By default, one SAS/SATA port and one USB port are set to perform as the source ports. The user has the flexibility to assign each target port of the unit as source or target.

This mode offers 100% bit-by-bit drive imaging. It works with any operating system and any file system, using a HASH verification mechanism that includes a HASH target drive and compares to the source drive for 100% verification of transferred data. The user can also image a portion of the drive by adjusting the percentage of the bit-by-bit mirror imaging.

Drives can also be duplicated in Quick Copy / Advanced Smart Copy mode. The application supports duplication of the files system only, from many source drives using FAT, NTFS, exFAT, HFS+, or Linux EXT2-4 file system to many target drives. Also, the application can automatically perform the following functions:

• Partitions scanning on the source drives
• Partitions scaling on the target drives
• Copy encrypted partition and unrecognized partition
• Scaling (options include scale all partitions, selectively scale partitions, disable scaling, and scale down partition)

This mode supports copying from source drives containing VHD files.

This mode supports selective capture of files and folders.

The application supports duplication of data from one source drive to many target drives, or from many source drives to many target drives up to 1:7 on SAS ports, 1:10 on SATA ports, and more on USB 3.1 ports.

This mode enables copying all data files from a source drive into one folder on the target drives.

The application supports independent channel/port erase operations using erase protocols such as DoD, Security Erase, Enhanced Security Erase, Sanitize, and User Erase mode.

The application supports quick formatting for NTFS, exFAT, FAT32, HFS+, and EXT4 file systems.

The user can run drive diagnostics on target drives. Supported diagnostics include S.M.A.R.T and Read-Verify tests, which report the location and number of bad sectors and weak media.

• Expandable via PCIe 3.0
• Application is updated to clone Windows 10 source drives
• Supports HFS+ partition in Quick Copy mode
• Copies across different types of storage interfaces
• Cloning from multiple source ports to multiple target ports
• Runs simultaneous, parallel, and independent duplication sessions
• Heavy duty, for 24/7 use
• Optional expansion box with eight additional SAS/SATA ports available separately
