Magewell Pro Convert IP to USB

The Magewell Pro Convert IP to USB is a plug-and-play UVC device that receives a single IP video stream and outputs it via USB-C, enabling IP-based workflows in conferencing, live streaming, and AV production environments. The compact unit supports NDI, NDI HX2, NDI HX3, and a wide range of streaming protocols, including SRT, RTMP, RTSP, and more. By offloading the decoding process to the device, the Pro Convert IP to USB minimizes CPU and GPU load on the host system while delivering 1080p60 video and two-channel embedded audio directly into compatible software.

The unit features a USB-C video output and host port, an RJ45 video input and control output port, and support for DHCP, remote PTZ camera control, and Magewell's Control Hub management platform. Designed for reliable operation and easy integration, the unit has robust protocol support, onboard processing, and broad compatibility.

Input and Output

• Decodes one IP video stream and outputs USB UVC up to 1920 x 1080 at 60 fps
• One RJ45 Ethernet input port (10/100/1000 Mb/s) and one USB-C 3.0 output port (5 Gb/s)
• Two-channels of embedded 16-bit, 48 kHz audio
• Accepts 5 VDC power at 1A via its USB-C port
• Supports USB NET for device communication

Configuration Management

• Configuration via Web UI or Magewell's Control Hub software
• Web UI allows firmware upgrades, diagnostics, and settings adjustments
• Remotely control PTZ cameras via NDI or Visca over UDP
• Supports HTTP APIs for custom integration
• Compatible with macOS, Windows, and Linux

EAN: 0814395021652
