HP Intel VROC for NVMe (Standard)

Designed for NVMe-based SSDs in HP's Z4, Z6, and Z8 G4 Workstations running Windows 7 or 10, and Xeon Skylake-W or Skylake-SP processors, this standard version of the Intel VROC for NVMe from HP is an enterprise RAID storage solution that supports RAID 0, 1, and 10 and lets users manage RAID volumes with NVMe SSDs that are directly connected to CPU PCIe lanes, without using a host bus adapter (HBA). Short for Virtual RAID on CPU, the Intel VROC delivers faster performance without the complexity and power of a traditional Hardware RAID HBA.

No need for battery backup / RAID maintenance free backup unit

Protected write back cache - software and hardware that allows recovery from a double fault

Isolated storage devices from OS for error handling

Boot from RAID volumes based on NVMe SSDs within a single Intel VMD domain

3 VMD domains per CPU provide for boot from one domain and data RAID spanning across the other 2 domains

RAID / storage management using representational state transfer (RESTful) application programming interfaces (APIs)

Graphical user interface (GUI) for Linux

4K native NVMe SSD support

Boot RAID (0, 1, and 10) on CPU-attached NVMe RAID volume

Spanning data RAID volumes across VMD domains

For NVMe RAID, Intel VROC is architected to use Intel VMD to provide the following features that Intel RSTe legacy NVMe RAID does not have:

• Bootable RAID
• Support for HP-qualified SSDs, as well as Intel SSDs

CPU attached NVMe SSD - high perf

Boot on RAID volume

Third party vendor SSD support

Intel RSTe 5.0 RAID 0, 1, and 10

Hot plug / surprise removal (2.5" SSD form factor only; Add-in card form factor not supported)

Enclosure LED management
