Crestron Flex Advanced Tabletop Small Room Conference System for Microsoft Teams Rooms

Set up a conference room for Microsoft Teams Rooms conferencing with the Flex Advanced Tabletop Small Room Conference System from Crestron. This hardware plus software solution is designed to enhance a small conference room with everything you need to run Microsoft Teams Rooms software with a single- or double-display setup. It also allows you to present using your own devices with its BYOD (Bring Your Own Device) setup.

The solution includes a tabletop conferencing device with a 7" touchscreen with a Teams Rooms UI, the UC-PR UC presentation transmitter, a bracket assembly with a mini PC running Windows 11 IoT with Microsoft Teams Rooms preinstalled, a PoE+ injector, as well as HDMI, USB, and Ethernet cables and adapters. Also included is a wall-mount kit for Crestron cameras. It can all be controlled via the XiO Cloud service with a separately available subscription.

Designed to enhance the Crestron Flex system, it features preinstalled Windows 11 IoT and Microsoft Teams Rooms conferencing software, enabling audio and video connectivity for easy collaboration and content sharing.

The included UC-2-T-V Crestron Flex Tabletop Conference device provides a powerful conferencing and collaboration experience for meeting rooms, huddle spaces, and executive offices. Its large 7" HD color touchscreen provides easy control and a Teams UI, and its integrated AEC-enabled USB speakerphone provides full-duplex wideband audio performance. It can be powered via PoE+ using the included PoE+ injector on a compatible network.

Conference room visitors can connect their laptops to the Crestron Flex system to use their own UC conference platform. The UC Presentation Transmitter (UC-PR) switches to the connected laptop's UC platform and returns to the native platform when disconnected.

The UC-MMX30-NC-T can integrate with a Crestron control system to enable touchscreen control of room lighting, motorized window shades, climate control, AV, and other amenities.

The included UC Bracket Assembly provides preassembled components on one ready-to-mount bracket to simplify installation. The assembly can be mounted on a wall, or it can be attached to the rear of the display device. Crestron's direct connection method further simplifies installation with a single connection from the Flex tabletop conference device or touchscreen to the UC Bracket Assembly.

High-definition video conferencing is supported by using the following Crestron 1 Beyond cameras, including the IV-CAM-P12-B, IV-CAM-P12-W, IV-CAM-P20-B, IV-CAM-P20-W, IV-CAM-I12-B, IV-CAM-I20-B, and IV-CAM-I20-W models. Microsoft Teams Rooms software-certified third-party cameras are also compatible with the system.

This kit enhances the Crestron Flex system, which is equipped for mass deployment throughout any sized corporate, university, medical, military, or government facility with enterprise-grade security.

The XiO Cloud service is an IoT cloud-based provisioning service that enables installers and IT managers to deploy and manage thousands of devices easily. It allows for system alerts, network management, provisioning, and the pairing of a control device to the system's UC Engine. System updates are controlled by Windows software update.
