COAX Connectors Korus UHD 12 GHz BNC Straight Crimp Plug for Belden 1794A/4794R (100-Pack)

This 100-pack of Korus UHD 12 GHz BNC Straight Crimp Plug for Belden 1794A/4794R from COAX Connectors is suitable for use at frequencies of 12 GHz. Supporting 12G signals, it is compatible with Belden 1794A/4794R, as well as similar cables in group FI. Tested to meet the requirements of SMPTE ST 2081-1 & ST 2082-1, typical applications are for 6G and 12G broadcast, telecom, instrumentation, security, and many others.

• Compatible with Belden 1794A and 4794R
• High-performance 75-ohm BNC crimp plug
• Tested to meet the requirements of SMPTE ST 2081-1 & ST 2082-1
• For use in 6G & 12G systems

• Center contact: brass
• Outer contact: brass
• Insulator: PTFE
• Bayonet cap: brass
• Centre contact plating: gold
• Outer contact plating: gold

• Impedance: 75 ohms
• Frequency range: up to 12 GHz
• Dielectric withstand voltage: 1500 Veff
• Insulation resistance: 5000 Megohms
• Return loss: -20 dB @ 6 GHz

• Design standard: IEC 61169-8
• RoHS 3 compliant: yes
• Centre contact termination: crimp
• Outer contact termination: crimp
• Mating cycles: 500
• Contact retention: 10 N min
• Cable retention: 150 N min
• Mating force: 13.6 N max
• Un-coupling force: 13.6 N max
• Center contact: Hex .172mm A/F
• Crimp sleeve: Hex 8.23mm A/F
