Cartoni C20S Fluid Head (100mm Ball)

The C20S Fluid Head from Cartoni allows you to execute smooth pan and tilt motions with a wide variety of camera rigs. The head features a 100mm ball base and a quick release plate with two 3/8"-16 screws. It is capable of supporting loads from 15.4 to 77.2 lb for both mid- and cine-sized gear. Three fluid damping modules ensure the 7-step +0 drag maintains smooth motion. A 7-step +0 counterbalance is controlled by an easy grip selector in both progressive steps and free adjustment. Secure the included telescopic pan bar to the right side of your fluid head to control your movements and utilize the illuminated spirit level to ensure the entire tripod is level.

The C20 S features an 8-position easy grip selector with a 60mm sliding balance plate, which allows the cameraperson to fine-tune the balancing of any camera and lens combination. An additional tilt angle can also be achieved by turning the tilt knob to the OFF position, provided the counterbalance selector ring has been previously set to "0".

Features 3-fluid damping modules, which assure outstanding, drag levels and extraordinary smoothness in both pan and tilt functions. Pan and tilt movements can be dampened with seven precisely repeatable steps of drag, while freewheeling is obtained by simply setting the relevant selector ring to position "0".

60mm sliding balance plate allows tilt angle to increase up to +/-60°.

Built-in illuminated spirit level allows easy setup, even in low-light conditions.

Maximum load capacity of 61 lb.

EAN: 4260725670414
